Electric storage water heater  Timberk Gra Series: N27C

Send to mail
Send
Choose a model
Equalization list
Added
Volume, l
Застраховано
Volume, l
100 一 30
Rated power consumption, W
2000
Heating element type
Brass
Location
Vertical
Control panel
Mechanical
The GRA series storage water heater has an excellent structural design in graphite color for your interior! It is a functional model that uniformly heats the water thanks to a streamlined overflow system.

Confirmed by the quality laboratory

About the device

Advantages

  • A textured body made of high-quality, heat-resistant plastic in a unique color scheme
  • A reliable copper heating element that has additional nickel plating
  • Intuitive controls with a mechanical thermostat on the bottom panel

Main characteristics

  • Compact, flat design, easy to install in any room
  • 3L Safety Protection System (3L SPS): Protection for the device against overheating, "dry" heating, overpressure inside the storage, and leakage
  • Enlarged layer of high-quality thermal insulation, significantly reduces heat losses
  • Readout for hookup to the electrical network
  • The set includes a 1.1 meter power cord.
Rated power consumption, W
2000
2000
2000
2000
Heating element type
Brass
Brass
Brass
Brass
Volume, l
30
50
80
100
Rated current, A
8.7
8.7
8.7
8.7
Rated supply voltage, V/Hz
220-240~/50
220-240~/50
220-240~/50
220-240~/50
Electrical protection class
I class
I class
I class
I class
Moisture protection class
IPX4
IPX4
IPX4
IPX4
Location
Vertical
Vertical
Vertical
Vertical
Heating time at Δ 30°C, min.
42
70
112
140
Actual annual electricity consumption, kW*h
405.1
512.6
588.3
670.5
Constant daily loss, kW*h/day
1.2
1.5
1.7
1.9
Nominal pressure, MPa
0.6
0.6
0.6
0.6
Control panel
Mechanical
Mechanical
Mechanical
Mechanical
Material of inner tank
Stainless steel
Stainless steel
Stainless steel
Stainless steel
The shape of the water heater
Flat
Flat
Flat
Flat
Количество режимов нагрева
3
3
3
3
Wire length, m
1.5
1.5
1.5
1.5
Weight (net), kg
9.86
13.79
19.36
22.79
Device dimensions, mm
540x435x258
815x435x258
945x496x393
1145x496x393

Scope of application

Electric storage water heaters (boilers) represent equipment designed for use on household and commercial premises if a centralized hot water supply system is temporarily or permanently absent. Storage water heaters are ideally suited to deliver hot water both to houses outside the city limits and apartments inside the city.

The water heaters are hooked up to a building’s regular electrical network, and can enable delivering hot water to several points of consumption. They differ from each other chiefly in terms of their cubic capacity (generally speaking, this ranges from 30 to 100 liters), the heating element’s power, the material from which the inner storage is manufactured, and the heating capacity.
